PreSonus StudioLive 32SX

StudioLive 32SX

Article number: 210000000673

€2.655,00

Incl. tax

With the 64-channel StudioLive® 64S and a full suite of integrated software, PreSonus delivers the most powerful and flexible digital console available for installed sound, touring, and recording—and the best value.

FEATURES

Portable, and flexible digital console for installed sound, mobile application, and recording with dual-core FLEX DSP Engine powering 286 simultaneous processors
Fully recallable, 40-input, 32-channel digital mixing console
Built-in AVB networking to create a complete ecosystem with PreSonus NSB stage boxes, EarMix 16M personal monitor mixers, and SW5E AVB switch
Built-in 128-channel (64x64) USB interface—the most of any mixer
Onboard multitrack SD Card recorder with true Virtual Soundcheck
16 FlexMixes (aux mixes, subgroups, or matrix mixes)
FLEX FX multieffects processor with 4 slots to load legendary reverb emulations and delays with 4 dedicated effects buses
Complete professional solution: suite of integrated software, including Studio One® Artist DAW and Capture.

Electronics

HEADPHONE JACK

1/4" TRS Active Stereo

VOLTAGE

220-240V EU

POWER REQUIREMENTS

85W (Continuous)

PHANTOM POWER

48 VDC, Switchable Per Channel (±2 VDC)

Performance

DIGITAL AUDIO BIT DEPTH

DIGITAL AUDIO DYNAMIC RANGE

ADC Dynamic Range: 115 dB (A-Weighted, 48 kHz), DAC Dynamic Range: 115 dB (A-Weighted, 48 kHz)

DIGITAL AUDIO REFERENCE LEVEL FOR ZERO DBFS

=+18 dBu

DIGITAL AUDIO TOTAL SYSTEM LATENCY

1.9 ms (local routing, analog in-analog out, all processing active)

Inputs

LINE INPUT CONNECTION TYPE

1/4" TRS Female, Balanced

LINE INPUTS FREQUENCY RESPONSE

20-20 kHz (±0.5 dBu at Unity Gain)

LINE INPUTS IMPEDANCE

10 kΩ

LINE INPUTS MAXIMUM LEVEL

=+18 dBu

LINE INPUTS SIGNAL TO NOISE RATIO

94 dB (Ref =+4 dB, 20 kHz BW, Unity Gain, A-Weighted)

LINE INPUTS TOTAL HARMONIC DISTORTION

<0.005%, +4 dBu, 20-20 kHz, Unity Gain, Unweighted

MICROPHONE INPUT CONNECTION TYPE

XLR Female, Balanced

MICROPHONE PREAMP COMMON MODE REJECTION RATIO

65 dB (1 kHz at Unity Gain)

MICROPHONE PREAMP FREQUENCY RESPONSE

20-20 kHz (±0.5 dBu at Unity Gain)

MICROPHONE PREAMP GAIN CONTROL RANGE

0 dB to +60 dB (±1 dB)

MICROPHONE PREAMP INPUT IMPEDANCE

1 kΩ

MICROPHONE PREAMP MAXIMUM INPUT LEVEL

=+12 dBu (Unity Gain)

MICROPHONE PREAMP SIGNAL TO NOISE RATIO

94 dB (Ref = +4 dB, 20 kHz BW, Unity Gain, A-Weighted)

MICROPHONE PREAMP TOTAL HARMONIC DISTORTION

<0.005%, +4 dBu, 20-20 kHz, Unity Gain, Unweighted

TAPE MAXIMUM INPUT LEVEL

+12 dBu, ±0.5 dBu

Outputs

HEADPHONE OUTPUTS FREQUENCY RESPONSE

20 Hz to 20 kHz, +/-0.5 dB

HEADPHONE OUTPUTS MAXIMUM OUTPUT

100 mW/ch. @ 60Ω load

HEADPHONE OUTPUTS SIGNAL TO NOISE RATIO

96 dB, 1 kHz, Maximum Gain, 20 Hz BW, Unweighted

HEADPHONE OUTPUTS TOTAL HARMONIC DISTORTION

0.01%, 1 kHz, Maximum Gain, 20 Hz BW, Unweighted

LINE OUTPUTS CONNECTION TYPE

1/4" TRS Female, Balanced

LINE OUTPUTS MAXIMUM OUTPUT LEVEL

=+18 dBu, ±0.5 dBu

LINE OUTPUTS OUTPUT IMPEDANCE

100 Ohms

TAPE MAXIMUM OUTPUT LEVEL

+18 dBu, ±0.5 dBu

TAPE OUTPUT IMPEDANCE

100 Ohms

Hardware

DIGITAL AUDIO AES EBU OUTPUT

XLR Male

DIGITAL AUDIO AVB AUDIO NETWORK PORTS

Locking XLR Ethernet

DIGITAL AUDIO NETWORK CONTROL PORT

RJ-45

DIGITAL AUDIO USB RECORDING PORT

USB 2.0, Type-B

TAPE CONNECTION TYPE

RCA Female, Unbalanced (Stereo Pair)
