This hybrid digital–analog full synthesizer voice, combines a multi-engine VCO (Classic, Wavetable and FM), multiple filter types, distortion, an assignable envelope, a randomizer and preset management, all within 12hp!

Features

• Digital core (16 bits - 48KHz) with full analog processing chain
• Three Synthesis Engines : Classic subtractive, wavetable and FM
• Four analog filter types (2 poles low-pass, high-pass, band-pass and 4 poles low-pass)
• VCA/LPG with distortion
• Built-in assignable envelope
• Gate-triggered randomizer with per-parameter depth
• Velocity input with independent scaling
• Memory of 256 presets, with both CV and Select Bus recall
• SD card for firmware update, user wavetables and presets management
• Expandable with up to two Ballista Blast Expanders
• DJ Tech Tools rubber injected knobs



  Specifications

  • Width: 12HP
  • Depth: 29mm
  • +12v: 135mA
  • -12v: 45mA
